ABB DAL13000 Counter Active Energy

€100,00
€100,00
Add to wishlist Remove from wishlist
Add to compare Remove from compare
ABB DAL13000 Counter Active Energy ABB DAL13000 Counter Active Energy ABB DAL13000 Counter Active Energy ABB DAL13000 Counter Active Energy ABB DAL13000 Counter Active Energy

ABB DAL13000 Active Energy Counter

Three-phase electronic active energy meter with LON interface for indirect/semi-indirect measurement

Overview

This is an ABB DAL13000 active energy counter, a three-phase electronic energy meter with neutral, designed for indirect/semi-indirect active power measurement. Rated for a 100-500VAC supply at 50/60Hz, this meter includes a LON communication interface and digital display, making it suited to energy monitoring and collection applications within commercial and industrial electrical systems.

Key Features

  • Three-phase active energy measurement: Three-phase with neutral configuration, measuring active power.
  • Wide voltage compatibility: Rated for 100-500VAC at 50/60Hz.
  • Defined current ratings: Rated current (IN) of 1A, with a maximum current (IMAX) of 6A.
  • 5000 imp/kWh pulse output: Provides a standard pulse rate for consumption tracking.
  • LON communication interface: Supports integration with LonWorks-based building or energy management systems.
  • Digital display: Provides clear local readout of measured energy values.
  • MID compliant: Admitted under the Measuring Instruments Directive (MID) for regulated energy metering applications.
  • DIN rail mounting: Mounts via a DIN rail adapter for straightforward panel installation.
  • Single tariff: Suited to applications requiring a single billing tariff rather than multi-rate metering.

What's Included

Model Function Qty
DAL13000 Three-phase active energy counter 1

Model: DAL13000 | Brand: ABB | Interface: LON | MID Compliant

Technical Specifications

Product type: DAL13000, active energy counter.

Voltage/frequency: 50/60Hz, 100-500VAC.

Pulse rate: 5000 imp/kWh.

Maximum current (IMAX): 6 A.

Rated current (IN): 1 A.

Number of meter tariffs: Single tariff.

Counter type: Electronic.

Number of phases: Three-phase with neutral.

Type of measured energy: Active power.

Suitable for collection: Yes.

Mounting method: DIN rail adapter.

Model/measurement type: Indirect / semi-indirect measurement.

Admission: MID (Measuring Instruments Directive).

Type of interface: LON.

Type of indicator: Digital.

Compatibility & Applications

This energy counter is suited to three-phase commercial and industrial electrical systems requiring MID-compliant active energy measurement with LON-based communication for integration into building or energy management systems. Buyers should confirm their system requires indirect/semi-indirect measurement (via current transformers) and that their monitoring platform supports the LON interface before installation.
