SMC ITV3030-04F4N3-Q 0.05-5 bar Pressure Regulator - NEW MISSING BOX

€260,00
€260,00
Add to wishlist Remove from wishlist
Add to compare Remove from compare
SMC ITV3030-04F4N3-Q 0.05-5 bar Pressure Regulator - NEW MISSING BOXSMC ITV3030-04F4N3-Q 0.05-5 bar Pressure Regulator - NEW MISSING BOXSMC ITV3030-04F4N3-Q 0.05-5 bar Pressure Regulator - NEW MISSING BOXSMC ITV3030-04F4N3-Q 0.05-5 bar Pressure Regulator - NEW MISSING BOXSMC ITV3030-04F4N3-Q 0.05-5 bar Pressure Regulator - NEW MISSING BOX

SMC ITV3030-04F4N3-Q Electro-Pneumatic Regulator — New, Missing Box

0.05-5 bar precision pneumatic pressure regulator with 4-20mA control and monitor output

Overview

The SMC ITV3030-04F4N3-Q is an electro-pneumatic regulator from the ITV1000/2000/3000 series, providing precise output pressure control from 0.05 to 5 bar based on an electrical input signal. It accepts current-type (4-20 mA or 0-20 mA DC) or voltage-type (0-5V or 0-10V DC) input signals and provides a 4-20 mA analog monitor output for pressure feedback. This unit is new but missing its original box — please review the provided photos carefully, as it's being sold without warranty and could not be tested prior to listing.

Key Features

  • Flexible input signal support: Accepts current-type (4-20 mA, 0-20 mA DC) or voltage-type (0-5V, 0-10V DC) control signals.
  • Analog monitor output: Provides a 4-20 mA DC output signal for real-time pressure feedback to a controller or PLC.
  • High flow capacity: Typical flow rate of 1500 L/min for responsive pressure regulation.
  • Precise set pressure range: Adjustable from 0.005 to 0.5 MPa (per this model's set pressure range), suited for sensitive pneumatic applications.
  • Low power consumption: Operates on 24VDC ±10% with current consumption of 0.12A or less.
  • IP65 protection with connector: Suitable for use in dusty or wet industrial environments.

What's Included

Item Function Qty
SMC ITV3030-04F4N3-Q Regulator Electro-pneumatic pressure regulator 1

Brand: SMC | Series: ITV2000 | Model: ITV3030-04F4N3-Q

Condition note: this item is new but was pulled from a working environment and is missing its original box. Some pictured units may show broken parts — please review photos carefully. Sold without warranty and untested; what you see is what you get. Please ask any questions before purchase.

Technical Specifications

Port connection: G 1/4.

Outlet pressure range: 0.05 to 5 bar.

Maximum input pressure: 10 bar.

Typical flow rate: 1500 L/min.

Minimum supply pressure: Set pressure + 0.1 MPa.

Maximum supply pressure: 1.0 MPa.

Set pressure range: 0.005 to 0.5 MPa.

Power supply: 24VDC ±10%; current consumption 0.12A or less.

Input signal: Current type 4-20 mA / 0-20 mA DC; voltage type 0-5V / 0-10V DC.

Input impedance: Current type 250Ω or less; voltage type approx. 6.5kΩ.

Output signal (monitor): 4-20 mA DC analog output (source type).

Compatibility & Applications

This regulator is well suited for pneumatic systems requiring precise, electronically controlled pressure regulation, such as process automation, testing equipment, and machinery requiring variable clamping or actuation force. Its analog input/output compatibility makes it a practical fit for integration with PLCs and control systems already using 4-20 mA or 0-10V signal standards.

A1Customer — Industrial Automation Equipment | Tampere, Finland
