Siemens Simatic 6ES7307-1BA01-0AA0 Regulated Power Supply

€90,00
€90,00
Add to wishlist Remove from wishlist
Add to compare Remove from compare
Siemens Simatic 6ES7307-1BA01-0AA0 Regulated Power SupplySiemens Simatic 6ES7307-1BA01-0AA0 Regulated Power SupplySiemens Simatic 6ES7307-1BA01-0AA0 Regulated Power SupplySiemens Simatic 6ES7307-1BA01-0AA0 Regulated Power SupplySiemens Simatic 6ES7307-1BA01-0AA0 Regulated Power Supply

1x Siemens Simatic 6ES7307-1BA01-0AA0 Regulated Power Supply

type of the power supply network 1-phase AC
supply voltage at AC
● initial value Automatic range selection
supply voltage
● 1 at AC rated value 120 V
● 2 at AC rated value 230 V
input voltage
● 1 at AC 85 ... 132 V
● 2 at AC 170 ... 264 V
design of input wide range input No
overvoltage overload capability 2.3 × Vin rated, 1.3 ms
operating condition of the mains buffering at Vin = 93/187 V
buffering time for rated value of the output current in the event of
power failure minimum
20 ms
operating condition of the mains buffering at Vin = 93/187 V
line frequency
● 1 rated value 50 Hz
● 2 rated value 60 Hz
line frequency 47 ... 63 Hz
current limitation of inrush current at 25 °C maximum 22 A
duration of inrush current limiting at 25 °C
● maximum 3 ms
I2t value maximum 1 A²·s
fuse protection type T 1.6 A/250 V (not accessible)
● in the feeder Recommended miniature circuit breaker: 3 A characteristic C
Output
voltage curve at output Controlled, isolated DC voltage
output voltage at DC rated value 24 V
output voltage
● at output 1 at DC rated value 24 V
relative overall tolerance of the voltage 3 %
relative control precision of the output voltage
● on slow fluctuation of input voltage 0.1 %
● on slow fluctuation of ohm loading 0.2 %
