Theben Selekta 174 top3 Time and light control Digital time switches

  • Theben Selekta 174 top3 Time and light control Digital time switches
  • Theben Selekta 174 top3 Time and light control Digital time switches
  • Theben Selekta 174 top3 Time and light control Digital time switches
  • Theben Selekta 174 top3 Time and light control Digital time switches
1 5

Theben Selekta 174 top3 Time and light control Digital time switches

€80,00
€80,00
Add to wishlist Remove from wishlist
Add to compare Remove from compare
Theben Selekta 174 top3 Time and light control Digital time switchesTheben Selekta 174 top3 Time and light control Digital time switchesTheben Selekta 174 top3 Time and light control Digital time switchesTheben Selekta 174 top3 Time and light control Digital time switches

1x Theben Selekta 174 top3 Time and light control Digital time switches
Technical data
SELEKTA 174 top3
Operating voltage 230 V AC
Frequency 50 – 60 Hz
Width 2 modules
Installation type DIN rail
Type of contact Changeover contact
Switching output Phase-independent
Opening width < 3 mm (µ)
Program Weekly program, Astronomical
program
Program functions ON-OFF
Number of channels 2
Number of memory locations 56
Power reserve 10 years
Switching capacity at 250 V AC, cos φ= 1 16 A
Switching capacity at 250 V AC, cos φ = 0,6 10 A
Incandescent/halogen lamp load 2600 W
Energy saving lamps 1100 W
LED lamp < 2 W 50 W
LED lamp 2-8 W 600 W
LED lamp > 8 W 600 W
SELEKTA 174 top3
Fluorescent lamp load (conventional) not corrected 2600 VA
Fluorescent lamp load (conventional) series-corrected 2600 VA
Fluorescent lamp load (conventional) parallel-corrected 1300 VA
Inrush current max. 800 A / 200 µs
Switching capacity min. ca. 10 mA
Shortest switching times 1 min
Time accuracy at 25 °C typical ± 0,25 s/day (quartz)
Time basis Quartz
Stand-by consumption ~0.4 W
Type of connection DuoFix spring terminals
Display LCD-Anzeige mit Textzeile
Keyboards 4 touch buttons
Housing and insulation material High-temperature resistant, selfextinguishing thermoplastic
Type of protection IP 20
Protection class II according to EN 60 730-1
Voltage 230 V AC
Ambient temperature -30°C ... 55°C
