Festo VUVS-L25-M52-MD-G14-F8 Single Solenoid Valve, 5/2 Monostable, 24V DC

Piston spool directional control valve with mechanical spring return

Overview

This is a Festo VUVS-L25-M52-MD-G14-F8, a single solenoid, 5/2-way monostable directional control valve from Festo's VUVS piston spool valve range. Electrically actuated with a mechanical spring reset, it switches pneumatic flow through a G1/4 pneumatic working port, delivering a standard nominal flow rate of 1300 l/min. Rated for a wide operating pressure range, it's built for reliable directional control in industrial pneumatic circuits.

Key Features

  • 5/2 monostable valve function: Electrically actuated with automatic mechanical spring return to default position.
  • High flow capacity: Standard nominal flow rate of 1300 l/min for demanding pneumatic circuits.
  • Piston gate valve design: Piston spool structural design for reliable, long-lasting switching performance.
  • Wide operating pressure range: Rated 2.5 to 10 bar (0.25 to 1 MPa) for flexible system integration.
  • UL Recognized: UL us Recognized (OL) certified for use in a wide range of industrial applications.
  • Maritime classification available: Certified under DNVGL-TAA000011J for marine and offshore applications.

What's Included

Model Function Qty
VUVS-L25-M52-MD-G14-F8 Single solenoid valve, 5/2 monostable, 24V DC 1

Technical Specifications

Valve function: 5/2, monostable.

Actuation type: Electrical (24V DC); mechanical spring reset.

Valve size: 26.5 mm; nominal width 6.9 mm.

Standard nominal flow rate: 1300 l/min.

Pneumatic working port: G1/4.

Operating pressure: 0.25-1 MPa (2.5-10 bar).

Structural design: Piston gate valve.

Certifications: UL us Recognized (OL); maritime classification per certificate DNVGL-TAA000011J.

Compatibility & Applications

Part of Festo's VUVS piston spool directional valve range, this solenoid valve is well suited to industrial pneumatic control applications requiring reliable, spring-return directional switching, including automated machinery, marine/offshore pneumatic systems, and general factory automation.
