Omron E32-T16 2M Fiber optic sensor head

  • Omron E32-T16 2M Fiber optic sensor head
1 4

Omron E32-T16 2M Fiber optic sensor head

€174,00
€174,00
Add to wishlist Remove from wishlist
Add to compare Remove from compare
Omron E32-T16 2M Fiber optic sensor headOmron E32-T16 2M Fiber optic sensor headOmron E32-T16 2M Fiber optic sensor head

Omron E32-T16 2M Fiber Optic Sensor Head, Through-Beam

Standard fiber sensor head for through-beam object detection with a compatible amplifier

Overview

This is an Omron E32-T16 2M, a through-beam fiber optic sensor head from the E32-T series, built for reliable object detection in demanding industrial environments. As a passive optical fiber head, it works alongside a compatible Omron fiber amplifier (such as the E3X-HD or E3NX-FA series), which supplies the light source and processes the received signal to detect objects passing through the beam.

Key Features

  • Through-beam sensing method: Emitter and receiver fiber ends face each other for accurate, reliable object detection as items pass between them.
  • 10 mm sensing area: Top-view sensing head suited to precise area detection in compact spaces.
  • Long sensing distance: Up to 4,000 mm when paired with a compatible E3NX-FA or E3X-HD series amplifier in standard mode.
  • 2 m fiber cable, free-cut capable: Standard plastic fiber can be trimmed to the exact length needed for a given installation.
  • IP67-rated sensor head: Resists dust and water ingress for use in harsh industrial environments.
  • Durable construction: ABS housing, plastic fiber core, and polyethylene sheath for extended service life; rated for -40°C to +70°C ambient operation.

What's Included

Model Function Qty
E32-T16 2M Through-beam fiber optic sensor head 1

Note: a compatible fiber amplifier (e.g., E3X-HD or E3NX-FA series) is required for operation and is not included with this sensor head.

Technical Specifications

Sensing method: Through-beam.

Sensing area: 10 mm.

Sensing distance: Up to 4,000 mm (with compatible E3NX-FA or E3X-HD amplifier, standard mode).

Fiber length: 2 m, free-cut standard plastic fiber.

Shape / orientation: Square head, top-view sensing surface.

Materials: ABS housing, plastic fiber core, polyethylene sheath.

Protection rating: IP67.

Operating temperature: -40°C to +70°C.

Compatibility & Applications

Compatible with Omron's E3X-HD and E3NX-FA series fiber amplifiers, this sensor head is well suited to compact-space object detection, presence sensing, and part positioning in manufacturing, packaging, and general industrial automation applications where a small, precise sensing point is needed.
