IMO SD1-4.2A-43 SD1 Torque Vector Inverter, 1.5kW, 3-Phase 400V

  • IMO SD1-4-2A-43 SD1 Inverter
1 10

IMO SD1-4.2A-43 SD1 Torque Vector Inverter, 1.5kW, 3-Phase 400V

€180,00
€180,00
Add to wishlist Remove from wishlist
Add to compare Remove from compare
IMO SD1-4-2A-43 SD1 InverterIMO SD1-4.2A-43 SD1 Torque Vector Inverter, 1.5kW, 3-Phase 400VIMO SD1-4.2A-43 SD1 Torque Vector Inverter, 1.5kW, 3-Phase 400VIMO SD1-4.2A-43 SD1 Torque Vector Inverter, 1.5kW, 3-Phase 400VIMO SD1-4.2A-43 SD1 Torque Vector Inverter, 1.5kW, 3-Phase 400VIMO SD1-4.2A-43 SD1 Torque Vector Inverter, 1.5kW, 3-Phase 400VIMO SD1-4.2A-43 SD1 Torque Vector Inverter, 1.5kW, 3-Phase 400VIMO SD1-4.2A-43 SD1 Torque Vector Inverter, 1.5kW, 3-Phase 400VIMO SD1-4.2A-43 SD1 Torque Vector Inverter, 1.5kW, 3-Phase 400V

IMO Precision Controls SD1-4.2A-43 Torque Vector Inverter, 1.5kW, 380-480V

General-purpose three-phase AC variable speed drive with built-in STO safety function

Overview

This is an IMO Precision Controls SD1-4.2A-43, a 1.5kW general-purpose AC variable speed drive from IMO's SD1 series, designed for three-phase motors operating on 380-480V AC. Using torque vector control technology, it delivers precise, efficient motor speed regulation, and comes with Safe Torque Off (STO, SIL2) functionality built in as standard — a safety feature normally found on more expensive inverter drives.

Key Features

  • Torque vector control: Delivers precise, efficient motor control and smooth speed regulation across a wide operating range.
  • Built-in Safe Torque Off (STO): SIL2-rated STO functionality included as standard, supporting safety-related motor stop applications.
  • Integrated communication: Built-in and field bus communication options for straightforward integration into automation networks.
  • Integrated EMC filter: Filter included as standard, simplifying compliance with electromagnetic compatibility requirements.
  • Metal housing, natural convection cooling: Durable metal construction with passive cooling, suited to clean, ventilated indoor installations.
  • Optional remote keypad: Compatible with IMO's SD1-KP and SD1-KP-CPY remote keypads for flexible operator interface placement.

What's Included

Model Function Qty
SD1-4.2A-43 Three-phase AC variable speed drive, 1.5kW 1

Technical Specifications

Rated output power: 1.5 kW.

Supply voltage: 3-phase, 380V (-15%) to 440V (+10%).

Rated input current: 5.0 A.

Rated output current: 4.2 A.

Protection rating: IP20.

Safety function: Safe Torque Off (STO), SIL2.

Cooling: Natural convection.

Compatibility & Applications

Configurable via IMO's Drives Studio / Workshop software, the SD1-4.2A-43 is suited to general industrial applications requiring speed adjustment, motor protection, and energy efficiency — including pumps, fans, conveyors, and other three-phase motor-driven equipment where a compact, feature-rich drive with built-in safety functionality is needed.
