SIEMENS MICROMASTER 420 6SE6420-2UD13-7AA1 0.37kW B02/1.17 FREQUENCY I

  •
1 9

SIEMENS MICROMASTER 420 6SE6420-2UD13-7AA1 0.37kW B02/1.17 FREQUENCY INVERTER

€325,00
€325,00
Add to wishlist Remove from wishlist
Add to compare Remove from compare
SIEMENS MICROMASTER 420 6SE6420-2UD13-7AA1 0.37kW B02/1.17 FREQUENCY INVERTERSIEMENS MICROMASTER 420 6SE6420-2UD13-7AA1 0.37kW B02/1.17 FREQUENCY INVERTERSIEMENS MICROMASTER 420 6SE6420-2UD13-7AA1 0.37kW B02/1.17 FREQUENCY INVERTERSIEMENS MICROMASTER 420 6SE6420-2UD13-7AA1 0.37kW B02/1.17 FREQUENCY INVERTERSIEMENS MICROMASTER 420 6SE6420-2UD13-7AA1 0.37kW B02/1.17 FREQUENCY INVERTERSIEMENS MICROMASTER 420 6SE6420-2UD13-7AA1 0.37kW B02/1.17 FREQUENCY INVERTERSIEMENS MICROMASTER 420 6SE6420-2UD13-7AA1 0.37kW B02/1.17 FREQUENCY INVERTERSIEMENS MICROMASTER 420 6SE6420-2UD13-7AA1 0.37kW B02/1.17 FREQUENCY INVERTER

The Siemens MICROMASTER 420 6SE6420-2UD13-7AA1 is a highly reliable and efficient frequency inverter designed for motor control applications. It offers a speed control range from 0Hz to 650Hz, with overload protection at 150% for up to 60 seconds. The inverter is equipped with DC and compound braking for efficient braking control. With a 3-phase input voltage of 380-480V (±10%) and an input current of 2.2A, this inverter provides exceptional performance in a compact design.

Model: 6SE6420-2UD13-7AA1
Rated Power: 0.37 kW
Frame Size: A (73mm Wide x 173mm High x 149mm Deep)
Protection Rating: IP20

Key Features:

  • Rated Power: 0.37 kW for compact motor control applications.
  • Overload Protection: 150% for 60 seconds for motor protection during peak loads.
  • Speed Control: Wide range from 0Hz to 650Hz for precise motor control.
  • Braking Functions: DC and compound braking for efficient braking performance.
  • Multiple Inputs/Outputs: Includes 1 Analogue Input, 3 Digital Inputs, 1 Analogue Output, and 1 Relay Output.
  • Input Voltage: 3-phase 380-480V AC (±10%), 47-63Hz for industrial applications.
  • Mounting Options: Wall mount or cubicle mount with 100mm ventilation space above and below.
  • Temperature Range: Suitable for environments with temperatures from -10°C to 50°C.
  • Compact Size: Frame size A (73mm x 173mm x 149mm), IP20 rated.
  • Mounting: Can be mounted on a symmetrical DIN rail or using 2 x M4 bolts.
