Telemecanique Safety Relay XPS-AL/SerieB

  • Telemecanique Safety Relay XPS-AL/SerieB
1 5

Telemecanique Safety Relay XPS-AL/SerieB

€27,00
€90,00
€27,00
Add to wishlist Remove from wishlist
Add to compare Remove from compare
Telemecanique Safety Relay XPS-AL/SerieBTelemecanique Safety Relay XPS-AL/SerieBTelemecanique Safety Relay XPS-AL/SerieBTelemecanique Safety Relay XPS-AL/SerieB

This Telemecanique Safety Relay XPS-AL/SerieB is designed to monitor safety circuits and ensure the safe operation of industrial equipment. Perfect for use in safety-related applications requiring compliance with performance standards.

Product Specifications:

  • Model: Telemecanique XPS-AL/SerieB
  • Supply Voltage:
    • 24 V AC: ±15%
    • 24 V DC: ±15%
  • Supply Frequency: 50/60 Hz
  • Power Consumption: 5 VA (AC)
  • Control Circuit Voltage (Uc): 24 V
  • Maximum Line Resistance: 90 Ohm
  • Breaking Capacity (Relay Output):
    • 180 VA holding (AC-15 C300)
    • 1800 VA inrush (AC-15 C300)
  • Relay Output Capacity:
    • 1.5 A at 24 V DC (DC-13)
    • Time Constant: 50 ms
    • Minimum Output Current: 10 mA
    • Minimum Output Voltage: 17 V
  • Thermal Current Rating:
    • 6 A per relay
    • Conventional Free Air Thermal Current (Ith): 18 A
  • Associated Fuse Rating:
    • 4 A gG or gL (relay output, conforms to EN/IEC 60947-5-1)
    • 6 A fast blow (relay output, conforms to EN/IEC 60947-5-1)
  • Response Time on Input Open: Maximum 40 ms
  • Input Protection: Internal electronic protection
  • Mounting: DIN rail mountable
  • Applications:
    • Suitable for use in industrial safety systems
    • Compatible with emergency stop devices, safety gates, and light curtains
  • Dimensions: Compact for control panel integration

Key Features:

  • High Breaking Capacity: Can handle significant electrical loads and provide reliable protection in safety circuits.
  • Fast Response Time: Ensures rapid safety actions in the event of system faults.
  • Easy Integration: Compatible with a variety of industrial safety equipment.
  • Reliable Protection: Built for long-term industrial use, providing protection against overloads and short circuits.
  • Conforms to Safety Standards: Meets EN/IEC 60947-5-1 for industrial safety relays.
